VENABIO® Flex
VENABIO® Flex
Thermoplastic elastomer
APPLICATIONS
This product satisfies the need for a heat sealable and weldable biopharmaceutical tubing. It provides disconnection and re-connection capabilities through a cuttable seal and aseptic welding.
It is important to mention that a thermoplastic is heat sensitive, so dry heat, SIP and autoclave sterilization cycles will shorten its life considerably, therefore it should only be used when the application is single use.
G.O.Science T: 031-375-6493 E-Mail : info@gosci.co.kr
FEATURES
CRUSH
PROOF BOX
>Individually packed rolls
>Printed CoA inside
>Labels on both bags and box
VACUUM
BAGGED
>Visual bag integrity proof
>Hydrogen peroxide vapour (HPV) disinfection cycle compatible
| Hardness | 70 ± 3 Shore A | Roll Length | Available in 25ft and 50ft |
| Tensile strength | > 5 Mpa | Laser Etched | Traceable with reference, lot number and ID/OD |
| Elongation | > 300% | Clean Room | Manufactured in ISO14644-1 Class 7 |
| Tear strength | - | Double Bag | Double bagged under vacuum |
| Density | 0.90 ± 0.02 g/cm³ | Smoothness | - |
| Outer Layer | Thermoplastic elastomer | Animal Free | Animal-derived products free |
| Temperature | -60˚C / +220˚C (-76˚F / +428˚F) | Radiostable | Gamma, e-Beam and X-Ray sterilization |
STERILIZATION
◈ Compatible with Gamma
◈ e-Beam and X-Ray
BIOCOMPATIBILITY
◈ ADCF, BSE/TSE free,
◈ BPA and Phthalate free
◈ EU 10/2011
◈ FDA 21CFR178.2010
◈ USP 87, USP 88, USP 661
◈ ISO 10993-4, ISO 10993-5
SPECIFICATIONS
CATALOG NO | METRIC (mm) | IMPERIAL (inches) | ||||
9200-8710-* | ID | OD | WALL | ID | OD | WALL |
| 9200-8710-0306 | 3.2 | 6.4 | 1.6 | 1/8 | 1/4 | 1/16 |
| 9200-8710-0508 | 4.8 | 7.9 | 1.6 | 3/16 | 5/16 | 1/16 |
| 9200-8710-0610 | 6.4 | 9.5 | 1.6 | 1/4 | 3/8 | 1/16 |
| 9200-8710-0611 | 6.4 | 11.1 | 2.4 | 1/4 | 7/16 | 3/32 |
| 9200-8710-0613 | 6.4 | 12.7 | 3.2 | 1/4 | 1/2 | 1/8 |
| 9200-8710-0813 | 7.9 | 12.7 | 2.4 | 5/16 | 1/2 | 3/32 |
| 9200-8710-0914 | 9.5 | 14.3 | 2.4 | 3/8 | 9/16 | 3/32 |
| 9200-8710-1016 | 9.5 | 15.9 | 3.2 | 3/8 | 5/8 | 1/8 |
| 9200-8710-1319 | 12.7 | 19.1 | 3.2 | 1/2 | 3/4 | 1/8 |
