AdvantaSil®: Pump Grade Silicone Tubing

Platinum-Cured; For Peristaltic Pump Applications

Class VI, platinum-cured silicone elastomer comprises AdvantaPure's peristaltic pump grade silicone tubing. Ideally suited for pharmaceutical, biotech, and laboratory environments, AdvantaSil® APSPG is specially formulated to withstand repeated compression and release for consistent, dependable performance – far outlasts standard silicone tubing. APSPG platinum cured pump tubing has undergone extensive physical, chemical, and biological testing, and meets USP Class VI, FDA CFR 177.2600, ISO 10993, and European Pharmacopoeia 3.1.9 standards. Full BPOG standardized extractables test protocol is in process with a fully-accredited, third-party test lab.

G.O.Science  T:  031-375-6493   E-Mail : info@gosci.co.kr


APSPG - SILICONE PUMP TUBING

Cat No
DescriptionWall (mm)

Standard Lengths

Coiled

APSPG-0031-0156
AdvantaSil® Silicone Pump Grade Tubing 1/32*5/32
1.5925FT
APSPG-0063-0188
AdvantaSil® Silicone Pump Grade Tubing 1/16*3/16
1.5925FT
APSPG-0125-0250
AdvantaSil® Silicone Pump Grade Tubing 1/8*1/4 1.5950FT
APSPG-0188-0313
AdvantaSil® Silicone Pump Grade Tubing 3/16*5/16
1.5950FT
APSPG-0250-0375
AdvantaSil® Silicone Pump Grade Tubing 1/4*3/8
1.5950FT
APSPG-0250-0438
AdvantaSil® Silicone Pump Grade Tubing 1/4*7/16
2.3850FT
APSPG-0250-0500
AdvantaSil® Silicone Pump Grade Tubing 1/4*1/2
3.1850FT
APSPG-0313-0500
AdvantaSil® Silicone Pump Grade Tubing 5/16*1/2
2.3850FT
APSPG-0375-0563
AdvantaSil® Silicone Pump Grade Tubing 3/8*9/16
2.3850FT
APSPG-0375-0625
AdvantaSil® Silicone Pump Grade Tubing 3/8*5/8
3.1850FT
APSPG-0500-0750
AdvantaSil® Silicone Pump Grade Tubing 1/2*3/4
3.1850FT

KEY FEATURES

  • Particulate testing per USP 788 is performed quarterly
  • All assembly and final packaging of extruded tubing is performed in an ISO Class 7 clean room
  • Special formulation promotes extended life in pumps
  • Outstanding compression characteristics – snaps back to original form
  • Smooth surfaces offer uniform fluid flow and resistance to bacteria build-up
  • AdvantaSil APSPG tubing is USP Class VI approved
  • Material meets FDA 21 CFR 177.2600
  • Low volatile grade suitable for pharmaceutical and biopharm applications
  • Translucent for visual contact with the flow
  • Certified free of animal-derived ingredients
  • Maximum operating temperature: 400°F (204.4°C); brittle temperature: less than -100°F (-73.3°C)
  • Sterilizable/autoclavable
  • Documented lot traceable with identification on packaging
  • Documented quality control per ISO 9001:2015
  • Included in our Rx-360 Joint Audit Program for Single-Use Systems
  • AdvantaFlex® biopharmaceutical grade tubing also available – heat sealable, weldable and moldable
  • Complete validation package available upon request
