Elastic compensator resistant to high pressure
Pharmaloader HPElastic compensator resistant to high pressure
Pharmaloader HP
Elastic compensator resistant to high pressure
Pharmaloader® HP is the ideal solution for all tank, hopper, pump, and weighing tank outlets to compensate vibrations and level differences. The product is a standard element fitted with molded clamp seals on the ends of the compensator.
APPLICATIONS
Pharmaloader®HP is the ideal solution for applications where it is necessary to a compensator that could resist high pressures.
G.O.Science T: 031-375-6493 E-Mail : info@gosci.co.kr
FEATURES
| Customization | ○ Outer later X: Black conductive silicone | Outer Layer | ○ VMQ Silicone, smooth or convoluted and translucent. |
| ○ Reinforcement Several plies of polyester fabric. | Reinforcement | ○ Two polyester fabric reinforcements and stainless steel counter-flange. | |
○ Inner Layer FKM for a higher resistance agains chemicals. | Inner Layer | ○ VMQ Silicone, smooth and translucent. | |
○ Traceability QR Marking Special marking | Temperature | ○ -50°C (-58°F) / +180°C (356°F). | |
| Manufacturing Length | ○ Custom made. | ||
| Vacuum Pressure | ○ Yes | ||
| Quality | ○ Complete Validation Package. | ||
SPECIFICATIONS
| NOMINAL CLAMP | CLAMP HEAD | INNER | OVERALL LENGTH | WAKING PRESSURE | ||
| inch | mm | mm | inch | mm | Bar | Psi |
| 1 1/2 | 50.5 | 34.7 | 4 | 102 | 5.7 | 14 |
| 2 | 64 | 47.5 | 4 | 102 | 4.0 | 12 |
| 3 | 91 | 73 | 6 | 152 | 2.6 | 8 |
