VENABIO® FEP
VENABIO® FEP
Fluorinated ethylene propylene tubing.
APPLICATIONS
This is a fluoropolymer tubing especially recommended for the most aggressive chemicals, pressurized gas transfer and abrasive particles in the pharmaceutical and biopharm processes.
G.O.Science T: 031-375-6493 E-Mail : info@gosci.co.kr
FEATURES
CRUSH
PROOF BOX
>Individually packed rolls
>Printed CoA inside
>Labels on both bags and box
VACUUM
BAGGED
>Visual bag integrity proof
>Hydrogen peroxide vapour (HPV) disinfection cycle compatible
| Hardness | 56 Shore D | Roll Length | Available in 25ft |
| Tensile strength | 30 Mpa | Universal | Universal chemical compatibility |
| Elongation | 325% | Low_permeability | Pressurized gas transfer |
| Outer Layer | Fluorinated ethylene propylene | Animal Free | Animal derived component free |
| Temperature | -200℃ / +205℃ (-328℉/ +421℉) | Radiostable | Gamma/eBeam sterilization available |
STERILIZATION
◈ Autoclave, CIP/SIP
◈ Ethylene oxide, Hydrogen peroxide
◈ eBeam (25kGy)*, Gamma (25kGy)*
* Sterilization available prior shipment.
BIOCOMPATIBILITY
◈ ADCF, BSE/TSE, P/BPA,
◈ FDA 21CFR177.1550
◈ USP 88
SPECIFICATIONS
CATALOG NO | METRIC (mm) | IMPERIAL (inches) | ||||
9220110* | ID | OD | WALL | ID | OD | WALL |
9220-1100-0082 | 0,8 | 1,6 | 0,4 | 1/32 | 1/16 | 1/64 |
9220-1100-0204 | 1,6 | 3,2 | 0,8 | 1/16 | 1/8 | 1/32 |
9220-1100-0305 | 3,2 | 5,2 | 1,0 | 1/8 | 11/54 | 3/76 |
9220-1100-0406 | 4,0 | 6,0 | 1,0 | 5/32 | 4/17 | 3/76 |
9220-1100-0507 | 4,8 | 6,8 | 1,0 | 3/16 | 4/15 | 3/76 |
9220-1100-0608 | 6,4 | 8,4 | 1,0 | 1/4 | 24/73 | 3/76 |
9220-1100-1012 | 9,5 | 11,5 | 1,0 | 3/8 | 5/11 | 3/76 |
9220-1100-1315 | 12,7 | 14,7 | 1,0 | 1/2 | 11/19 | 3/76 |
