VENABIO® PTFE
VENABIO® PTFE
Politetrafluoroethylene
APPLICATIONS
This is a fluoropolymer tubing especially recommended for the most aggressive chemicals, pressurized gas transfer and abrasive particles in the pharmaceutical and biopharm processes.
G.O.Science T: 031-375-6493 E-Mail : info@gosci.co.kr
FEATURES
CRUSH
PROOF BOX
>Individually packed rolls
>Printed CoA inside
>Labels on both bags and box
VACUUM
BAGGED
>Visual bag integrity proof
>Hydrogen peroxide vapour (HPV) disinfection cycle compatible
| Hardness | 56 Shore D | Roll Length | Available in 25ft |
| Tensile strength | 34 Mpa | Universal | Universal chemical compatibility |
| Elongation | 410% | Low_permeability | Pressurized gas transfer |
| Outer Layer | Politetrafluoroethylene | Animal Free | Animal derived component free |
| Temperature | -200℃ / +205℃ (-328℉/ +421℉) | Radiostable | - |
STERILIZATION
◈ Dry heat, Autoclave, CIP/SIP
◈ Ethylene oxide, Hydrogen peroxide
BIOCOMPATIBILITY
◈ ADCF, BSE/TSE, P/BPA,
◈ FDA 21CFR177.1550
◈ USP 88
SPECIFICATIONS
CATALOG NO | METRIC (mm) | IMPERIAL (inches) | ||||
92200120* | ID | OD | WALL | ID | OD | WALL |
9220-1200-0406 | 4,0 | 6,0 | 1,0 | 5/32 | 4/17 | 3/76 |
9220-1200-0507 | 5,0 | 7,0 | 1,0 | 12/61 | 8/29 | 3/76 |
9220-1200-0608 | 6,0 | 8,0 | 1,0 | 13/55 | 23/73 | 3/76 |
9220-1200-0810 | 8,0 | 10,0 | 1,0 | 5/16 | 9/23 | 3/76 |
9220-1200-1012 | 10,0 | 12,0 | 1,0 | 37/94 | 43/91 | 3/76 |
9220-1200-1214 | 12,0 | 14,0 | 1,0 | 43/91 | 43/78 | 3/76 |
