FEATURES
CRUSH
PROOF BOX
>Individually packed rolls
>Printed CoA inside
>Labels on both bags and box
VACUUM
BAGGED
>Visual bag integrity proof
>Hydrogen peroxide vapour (HPV) disinfection cycle compatible
| Hardness | 62.5 Shore A | Roll Length | Available in 25ft and 50ft |
| Tensile strength | >80 N/mm² | Laser Etched | Traceable with reference, lot number and ID/OD |
| Elongation | >250% | Clean Room | Manufactured in ISO14644-1 Class 7 |
| Tear strength | >21 kN/m | Double Bag | Double bagged under vacuum |
| Density | 0.92 g/cm³ | Smoothness | Reduces protein binding and biofilm formation |
| Outer Layer | Thermoplastic vulcanizate | Animal Free | Animal derived component free |
| Temperature | -45℃ / +135℃ (-49℉/ +275℉) | Radiostable | Gamma/eBeam sterilization available |
STERILIZATION
◈ Autoclave, CIP/SIP
◈ Ethylene oxide, Hydrogen peroxide
◈ eBeam (25kGy)*, Gamma (25kGy)*
* Sterilization available prior shipment.
BIOCOMPATIBILITY
◈ ADCF, BSE/TSE, P/BPA,
◈ FDA 21CFR177.2600
◈ USP 87, USP 88
◈ ISO 10993-4, ISO 10993-5
SPECIFICATIONS
CATALOG NO | METRIC (mm) | IMPERIAL (inches) | ||||
9200881* | ID | OD | WALL | ID | OD | WALL |
9200-8810-0205 | 1,6 | 4,8 | 1,6 | 1/16 | 3/16 | 1/16 |
9200-8810-0306 | 3,2 | 6,4 | 1,6 | 1/8 | 1/4 | 1/16 |
9200-8810-0508 | 4,8 | 7,9 | 1,6 | 3/16 | 5/16 | 1/16 |
9200-8810-0610 | 6,4 | 9,5 | 1,6 | 1/4 | 3/8 | 1/16 |
9200-8810-0611 | 6,4 | 11,1 | 2,4 | 1/4 | 7/16 | 3/32 |
9200-8810-0811 | 7,9 | 11,1 | 1,6 | 5/16 | 7/16 | 1/16 |
9200-8810-0813 | 7,9 | 12,7 | 2,4 | 5/16 | 1/2 | 3/32 |
9200-8810-1014 | 9,5 | 14,3 | 2,4 | 3/8 | 9/16 | 3/32 |
9200-8810-1016 | 9,5 | 15,9 | 3,2 | 3/8 | 5/8 | 1/8 |
9200-8810-1319 | 12,7 | 19,1 | 3,2 | 1/2 | 3/4 | 1/8 |
