VENABIO® Precision
VENABIO® Precision
Platinum-cured silicone tubing
APPLICATIONS
This product is the workhorse for the majority of fluid management applications happening in manufacturing and filling plants. It is used upstream from the media prep to the harvest stage and downstream all the way from the first filtration stages to the final filling.
This hardness provides a compromise in pumping performance and the little pressures generated by filter incorporation to the fluid path.
지오사이언스 T : 031-375-6493 E-Mail : info@gosci.co.kr
FEATURES
CRUSH
PROOF BOX
>Individually packed rolls
>Printed CoA inside
>Labels on both bags and box
VACUUM
BAGGED
>Visual bag integrity proof
>Hydrogen peroxide vapour (HPV) disinfection cycle compatible
| Hardness | 60 Shore A | Roll Length | Available in 50ft and 100ft |
| Tensile strength | >7 N/mm² | Laser Etched | Traceable with reference, lot number and ID/OD |
| Elongation | >300% | Clean Room | Manufactured in ISO14644-1 Class 7 |
| Tear strength | >20 kN/m | Double Bag | Double bagged under vacuum |
| Density | 1,17 g/cm³ | Smoothness | Reduces protein binding and biofilm formation |
| Outer Layer | Platinum cured silicone. Postcured to completely eliminate volatiles | Animal Free | Animal derived component free |
| Temperature | -60℃ / +220℃ (-76℉/ +428℉) | Radiostable | Gamma/eBeam sterilization available |
STERILIZATION
◈ Dry heat, Autoclave, CIP/SIP
◈ Ethylene oxide, Hydrogen peroxide
◈ eBeam (25kGy)*, Gamma (25kGy)*
* Sterilization available prior shipment.
BIOCOMPATIBILITY
◈ ADCF, BSE/TSE, Extractables & Leachables, P/BPA,
◈ EU 10/2011, EU 1935/ 2004
◈ BfR XV, 3A 18-03
◈ EP/ 3.1.9., FDA 21CFR177.2600
◈ USP 85, USP 87, USP 88, USP 381, USP 788
◈ ISO 10993-4, ISO 10993-5, ISO 10993-6, ISO 10993-10, ISO 10993-11
SPECIFICATIONS
CATALOG NO | METRIC (mm) | IMPERIAL (inches) | PUMP | ||||
92008521* | ID | OD | WALL | ID | OD | WALL | SIZE |
| 9200-8521-0054 | 0,5 | 3,7 | 1,6 | 1/51 | 7/48 | 1/16 | 112 |
9200-8521-0084 | 0,8 | 4,0 | 1,6 | 1/32 | 5/32 | 1/16 | 13 |
9200-8521-0104 | 1,2 | 4,4 | 1,6 | 3/64 | 11/64 | 1/16 | |
9200-8521-0105 | 1,6 | 4,8 | 1,6 | 1/16 | 3/16 | 1/16 | 14 |
9200-8521-0307 | 3,2 | 6,8 | 1,8 | 1/8 | 15/56 | 1/14 | |
9200-8521-1509 | 4,8 | 8,8 | 2,0 | 3/16 | 10/29 | 10/127 | |
9200-8521-0610 | 6,0 | 10,2 | 2,1 | 6/25 | 31/78 | 10/127 | |
9200-8521-0812 | 8,0 | 12,4 | 2,2 | 5/16 | 39/83 | 10/127 | |
