Vena® Sil 650VPolyester fabric and wire reinforced silicone hose

Vena® Sil 650V

Polyester fabric and wire reinforced silicone hose / Complete validation package


Highly flexible FDA and USP VI platinum cured silicone hose with stainless steel wire and polyester fabric reinforcement, for food and pharma processing.

APPLICATIONS

It's especially recommended for the transport of liquid or semi-liquids in the food, cosmetic and pharmaceutical industries. It offers an extremely broad field of applications. The design ensures a balance between strength and lightness, making it easy to handle. Can be used in filling machines with repetitive movements and when a small bend radius is required. Can work by impulsion (pressure) or suction (vacuum).

G.O.Science  T:  031-375-6493   E-Mail : info@gosci.co.kr

FEATURES

Customization

○ Outer Layer

   Telcra: Innovative insulating material.

   X: Black conductive silicone.

   Lastic: High elastic silicone, exclusive Venair formulation.

   FR-HL: Flame retardant version in accordance to EN-45545-2.

Outer Layer
○ VMQ Silicone, smooth and translucent
○ Reinforcement
   AC: Copper wire spiral to improve static electricity discharge
Reinforcement
○ Stainless steel wire and polyester fabric reinforcement

○ Traceability

   Silicone label

   QR Marking

   Special marking

Inner Layer
○ VMQ Silicone, smooth and translucent

○ Assemblies

   316L Stainless steel SZR crimp fittings

   Molded clamps

Temperature
○ -55ºC / +180ºC (-67ºF / 356ºF)
Manufacturing Length
○ 4m (13.12ft). 6m (19.69ft) for standard diameters.
Vacuum Pressure
○ 0.91 Bar (13.23 psi)
Quality

○ Complete validation package

SPECIFICATIONS

INNER DIAMETER
WALL THICKNESS
WORKING PRESSURE
BURSTING PRESSURE
BENDING RADIUS
VACUUM
RESISTANCE
mm
inch
mm
inch
Bar at 20℃
Psi at 68℉
Bar at 20℃
Psi at 68℉
mm
inch
6
1/4
5,5
0,22
26
377
77,9
1130
29
1,14
684 Torr (mmHg)
0,91 bar
13,23 psi
26,93 inHg
9,29 m H2O
10
3/8
5,5
0,22
22
318
65,9
955
34
1,34
13
1/2
5,5
0,22
19,9
289
59,7
866
39
1,54
19
3/4
5,5
0,22
16,5
240
49,6
719
54
2,13
25
1
5,5
0,22
14,8
214
44,3
643
68
2,68
32
1 1/4
5,5
0,22
12,8
186
38,5
558
94
3,7
38
1 1/2
5,5
0,22
11,5
167
34,5
500
112
4,41
51
2
5,5
0,22
9,2
133
27,5
399
144
5,67
63
2 1/2
5,5
0,22
7,5
109
22,6
327
181
7,13
76
3
6
0,24
6,1
88
18,2
263
232
9,13
102
4
6
0,24
3,7
54
11,2
163
367
14,45

QR marking

The QR hose label can be marked in any FDA silicone hose without distorting any characteristic of the hose. This hose label assures 100% traceability allowing to have a more efficent system for product data reading. It’s an alternative to the chip system, the most commonly used in the market, however, it presents much more advantages:

  • It is marked in the silicone with a laser which makes it indelible
  • It doesn’t need any additional software
  • Can be read with all kind of mobile device which has downloaded an app to read codes, which are completely free
  • Can provide unlimited amounts of information about the product allowing you to customize the data content

Silicone color labels

Venair also offers the possibility to include silicone labels over any hose in order to mark specific information that you require.

Labels offer clear identification, cleanliness and permanence in the silicone hose. The label is not in contact with the inner liquid and it’s made of permanent vulcanized silicone, certified free of animal-derived ingredients. Additionally, handles CIP and SIP processes and it’s autoclavable.

Silicone labels can be customized with more than 15 colors in order to meet your specific needs such as part number, manufacturing date, replacement date, or any specific information that you consider to be important.
