Vena® Sil 650V Lastic
Reinforced silicone hose, produced with a highly elastic silicone,
formulated by Venair / Complete validation package
Highly elastic FDA and USP VI platinum cured silicone hose, formulated by Venair, with stainless steel wire and polyester fabric reinforcement, for food and pharma processing.
APPLICATIONS
It's especially recommended for the transport of liquid or semi-liquids in the food, cosmetic and pharmaceutical industries. It offers an extremely broad field of applications. The design ensures a balance between strength and lightness, making it easy to handle. Can be used in filling machines with repetitive movements and when a small bend radius is required. Can work by impulsion (pressure) or suction (vacuum).
G.O.Science T: 031-375-6493 E-Mail : info@gosci.co.kr
FEATURES
| Customization | ○ Outer Layer Telcra: Innovative insulating material. X: Black conductive silicone. FR-HL: Flame retardant version in accordance to EN-45545-2. | Outer Layer | ○ Special highly elastic silicone, smooth and translucent. |
| ○ Reinforcement AC: Copper wire spiral to improve static electricity discharge | Reinforcement | ○ Stainless steel wire and polyester fabric reinforcement | |
○ Traceability Silicone label QR Marking Special marking | Inner Layer | ○ Special highly elastic silicone, smooth and translucent. | |
○ Assemblies Molded clamps Standard fittings Custom fittings Clamp fittings with an inner cover of PFA (Under request) 316L stainless steel fittings on each end with a roughness value of less than 0.8 µm (or 0.5 µm on request) crimped with SZR system (no retention area) | Temperature | ○ -55ºC / +180ºC (-67ºF / 356ºF) | |
| Manufacturing Length | ○ 4m (13.12ft). 6m (19.69ft) for standard diameters. | ||
| Vacuum Pressure | ○ 0.91 Bar (13.23 psi) | ||
| Quality | ○ FDA-CFR 21, item 177.2600: "Rubber articles for contact with food and drugs". ResAp 2004 (5), according to Reg 1935/2004/EEC, and Reg 10/2011/EEC USP Class VI standard -121ºC standard. | ||
SPECIFICATIONS
INNER DIAMETER | WALL THICKNESS | WORKING PRESSURE | BURSTING PRESSURE | BENDING RADIUS | |||||
mm | inch | mm | inch | Bar at 20℃ | Psi at 68℉ | Bar at 20℃ | Psi at 68℉ | mm | inch |
6 | 1/4 | 5.5 | 0.22 | 23.5 | 340.7 | 70.5 | 1022.1 | 15 | 0.6 |
8 | 5/16 | 5.5 | 0.22 | 21.4 | 310.3 | 64.2 | 931.0 | 15 | 0.6 |
10 | 3/8 | 5.5 | 0.22 | 19.8 | 286.8 | 59.3 | 860.3 | 15 | 0.6 |
13 | 1/2 | 5.5 | 0.22 | 17.9 | 259.1 | 53.6 | 777.2 | 15 | 0.6 |
16 | 5/8 | 5.5 | 0.22 | 16.3 | 237.1 | 49.0 | 711.4 | 15 | 0.6 |
19 | 3/4 | 5.5 | 0.22 | 15.1 | 219.0 | 45.3 | 657.0 | 15 | 0.6 |
22 | 7/8 | 5.5 | 0.22 | 14.0 | 203.5 | 42.1 | 610.5 | 15 | 0.6 |
25 | 1 | 5.5 | 0.22 | 13.1 | 190.0 | 39.3 | 570.0 | 25 | 1.0 |
32 | 1 1/4 | 5.5 | 0.22 | 11.3 | 163.9 | 33.9 | 491.8 | 49 | 1.9 |
38 | 1 1/2 | 5.5 | 0.22 | 10.1 | 145.8 | 30.2 | 437.4 | 69 | 2.7 |
51 | 2 | 5.5 | 0.22 | 7.9 | 114.7 | 23.7 | 344.1 | 114 | 4.5 |
63 | 2 1/2 | 5.5 | 0.22 | 6.4 | 92.4 | 19.1 | 277.2 | 155 | 6.1 |
76 | 3 | 6.0 | 0.24 | 5.0 | 72.6 | 15.0 | 217.8 | 200 | 7.9 |
102 | 4 | 6.0 | 0.24 | 2.9 | 41.5 | 8.6 | 124.6 | 290 | 11.4 |
QR marking
The QR hose label can be marked in any FDA silicone hose without distorting any characteristic of the hose. This hose label assures 100% traceability allowing to have a more efficent system for product data reading. It’s an alternative to the chip system, the most commonly used in the market, however, it presents much more advantages:
Silicone color labels
Venair also offers the possibility to include silicone labels over any hose in order to mark specific information that you require.
Labels offer clear identification, cleanliness and permanence in the silicone hose. The label is not in contact with the inner liquid and it’s made of permanent vulcanized silicone, certified free of animal-derived ingredients. Additionally, handles CIP and SIP processes and it’s autoclavable.
Silicone labels can be customized with more than 15 colors in order to meet your specific needs such as part number, manufacturing date, replacement date, or any specific information that you consider to be important.
