Polyester fabric and double wire reinforced silicone hose
Vena® Sil 655Polyester fabric and double wire reinforced silicone hose
Vena® Sil 655
Polyester fabric and double wire reinforced silicone hose
/ Complete validation package
Highly flexible FDA and USP VI platinum cured silicone hose with double stainless steel wire and polyester fabric reinforcement, for food and pharma processing.
APPLICATIONS
It is especially recommended for the transport of liquid or semi-liquid fluids in the food, cosmetic and pharmaceutical industries. This is a hose with a high level of strength. It has been designed for the use at specific points where there may be sudden high-pressure surges (hammering). It is the one with the highest level of strength and robustness of our standard silicone range. Can work by impulsion (pressure) or suction (vacuum).
G.O.Science T: 031-375-6493 E-Mail : info@gosci.co.kr
FEATURES
| Costomization | ○ Outer Layer Telcra: Innovative insulating material. X: Black conductive silicone. Lastic: High elastic silicone, exclusive Venair formulation. FR-HL: Flame retardant version in accordance to EN-45545-2. | Outer Layer | ○ VMQ Silicone, smooth and translucent. |
| ○ Reinforcement AC: Copper wire spiral to improve static electricity discharge | Reinforcement | ○ Double stainless steel wire spring and polyester fabric reinforcement. | |
○ Traceability Silicone label QR Marking Special marking | Inner Layer | ○ VMQ Silicone, smooth and translucent. | |
○ Assemblies 316L Stainless steel SZR crimp fittings Molded clamps | Temperature | ○ From -55ºC (-67ºF) to +180ºC (356ºF). Can reach up to +200ºC (392ºF) during short periods of time. | |
| Manufacturing Length | ○ 4m (13.12ft). 6m (19.69ft) for standard diameters. | ||
| Vacuum Pressure | ○ 0.91 Bar (13.23 psi) | ||
| Quality | ○ Complete validation package | ||
SPECIFICATIONS
INNER DIAMETER | WALL THICKNESS | WORKING PRESSURE | BURSTING PRESSURE | BENDING RADIUS | VACUUM RESISTANCE | |||||
mm | inch | mm | inch | Bar at 20℃ | Psi at 68℉ | Bar at 20℃ | Psi at 68℉ | mm | inch | |
6 | 1/4 | 5,5 | 0,26 | 31,5 | 456 | 94,5 | 1370 | 43 | 1,69 | 684 Torr (mmHg) 0,91 bar 13,23 psi 26,93 inHg 9,29 m H2O |
10 | 3/8 | 5,5 | 0,26 | 27 | 392 | 81 | 1174 | 49 | 1,93 | |
13 | 1/2 | 5,5 | 0,26 | 24,5 | 355 | 73,5 | 1066 | 54 | 2,13 | |
19 | 3/4 | 5,5 | 0,26 | 20,5 | 297 | 61,5 | 892 | 68 | 2,68 | |
25 | 1 | 5,5 | 0,26 | 18,5 | 268 | 55,5 | 805 | 80 | 3,15 | |
32 | 11/4 | 5,5 | 0,26 | 16,5 | 239 | 49,5 | 718 | 100 | 3,94 | |
38 | 11/2 | 6,5 | 0,28 | 15 | 218 | 45 | 653 | 121 | 4,76 | |
51 | 2 | 6,5 | 0,28 | 12 | 174 | 36 | 522 | 185 | 7,28 | |
63 | 21/2 | 6,5 | 0,28 | 10 | 145 | 30 | 435 | 273 | 10,75 | |
76 | 3 | 6,5 | 0,28 | 7,1 | 103 | 21,3 | 308 | 318 | 12,52 | |
102 | 4 | 6,5 | 0,28 | 5 | 73 | 15 | 218 | 423 | 16,65 | |
QR marking
The QR hose label can be marked in any FDA silicone hose without distorting any characteristic of the hose. This hose label assures 100% traceability allowing to have a more efficent system for product data reading. It’s an alternative to the chip system, the most commonly used in the market, however, it presents much more advantages:
Venair also offers the possibility to include silicone labels over any hose in order to mark specific information that you require.
Labels offer clear identification, cleanliness and permanence in the silicone hose. The label is not in contact with the inner liquid and it’s made of permanent vulcanized silicone, certified free of animal-derived ingredients. Additionally, handles CIP and SIP processes and it’s autoclavable.
Silicone labels can be customized with more than 15 colors in order to meet your specific needs such as part number, manufacturing date, replacement date, or any specific information that you consider to be important.
