Highly abrasion resistant polyurethane hose
Vena® Technipur® S200Highly abrasion resistant polyurethane hose
Vena® Technipur® S200
Highly abrasion resistant polyurethane hose
Flexible and fully smooth FDA polyurethane hose to convey bulks and powder materials in the food and pharmaceutical industries.
APPLICATIONS
This product is especially recommended for transport of all types of abrasive particles, such as granular products, salt, sugar and powder of all types for food and pharma applications. The smooth inner and outer finishing makes it easy to clean and allows a constant flow reducing the pressure losses. Due its robust construction is not recommended for small bend radius.
G.O.Science T: 031-375-6493 E-Mail : info@gosci.co.kr
FEATURES
| Material | ○ Material Technipur S200-X: (conductive material with low electrical surface resistivity) | Outer Layer | ○ Polyurethane, smooth and translucent. |
| Reinforcement | ○ Reinforcement Technipur S200 AC: copper wire spiral to help the discharge of static electricity. | Reinforcement | ○ Stainless steel wire spring. |
| Traceability | ○ Traceability QR Marking Special marking | Inner Layer | ○ Polyurethane, smooth and translucent. |
| Assemblies | ○ Assemblies Standard fittings Custom fittings Crimped fittings (SZR systems- Non retention area) Clamp fittings with an inner cover of PFA (Under request) 316L stainless steel fittings on each end with a roughness value of less than 0.8 µm (or 0.5 µm on request). | Temperature | ○ From -20ºC (-4ºF) to +80ºC (176ºF). |
| Manufacturing Length | ○ 10m (33 ft.) | ||
| Vacuum Pressure | ○ Yes | ||
| Quality | ○ FDA-CFR 21, item 177.1680 and CFR 177.2600. ○ ResAp 2004 (5), according to Reg 1935/2004/EEC, and Reg 10/2011/EEC. | ||
SPECIFICATIONS
| INNER DIAMETER | WALL THICKNESS | WORKING PRESSURE | BURSTING PRESSURE | ||||
| mm | inch | mm | inch | Bar at 20℃ | Psi at 68℉ | Bar at 20℃ | Psi at 68℉ |
| 13 | 0,51 | 4,50 | 0,18 | 12,17 | 176,47 | 36,50 | 529,25 |
| 16 | 0,63 | 4,50 | 0,18 | 11,54 | 167,33 | 34,61 | 501,84 |
| 20 | 0,79 | 4,50 | 0,18 | 10,73 | 155,51 | 32,18 | 466,54 |
| 25 | 0,98 | 4,50 | 0,18 | 9,75 | 141,43 | 29,26 | 424,29 |
| 30 | 1,18 | 4,50 | 0,18 | 8,83 | 128,02 | 26,49 | 384,06 |
| 32 | 1,26 | 4,50 | 0,18 | 8,47 | 122,85 | 25,42 | 368,54 |
| 35 | 1,38 | 4,50 | 0,18 | 7,95 | 115,29 | 23,85 | 345,87 |
| 38 | 1,5 | 4,50 | 0,18 | 7,45 | 107,98 | 22,34 | 323,93 |
QR marking
The QR hose label can be marked in any FDA silicone hose without distorting any characteristic of the hose. This hose label assures 100% traceability allowing to have a more efficent system for product data reading. It’s an alternative to the chip system, the most commonly used in the market, however, it presents much more advantages:
