Customization	○ Outer later Telcra- Insulating material	Outer Layer	○ VMQ Silicone, smooth and translucent
	○ Reinforcement AC: Copper wire spiral to improve static electricity discharge. Plastic wire (Vena Sil 650V Plastic).	Reinforcement	○ Stainless steel wire spring and polyester fabric reinforcement.
	○ Traceability Silicone label QR Marking Special marking	Inner Layer	○ PFA fluoropolymer, smooth and white.
	○ Assemblies 316L Stainless steel SZR crimp fittings Molded clamps	Temperature	○ -30ºC / +150ºC (-22ºF / 302ºF)
		Manufacturing Length	○ 20m (65.62 ft). Can be cutted under request.
		Vacuum Pressure	○ 0.9 Bar (13.05 psi).
Quality	○ -

The QR hose label can be marked in any FDA silicone hose without distorting any characteristic of the hose. This hose label assures 100% traceability allowing to have a more efficent system for product data reading. It’s an alternative to the chip system, the most commonly used in the market, however, it presents much more advantages:

It is marked in the silicone with a laser which makes it indelible
It doesn’t need any additional software
Can be read with all kind of mobile device which has downloaded an app to read codes, which are completely free
Can provide unlimited amounts of information about the product allowing you to customize the data content

Venair also offers the possibility to include silicone labels over any hose in order to mark specific information that you require.

Labels offer clear identification, cleanliness and permanence in the silicone hose. The label is not in contact with the inner liquid and it’s made of permanent vulcanized silicone, certified free of animal-derived ingredients. Additionally, handles CIP and SIP processes and it’s autoclavable.

Silicone labels can be customized with more than 15 colors in order to meet your specific needs such as part number, manufacturing date, replacement date, or any specific information that you consider to be important.

INNER DIAMETER		WALL THICKNESS		WORKING PRESSURE		BENDING RADIUS
mm	inch	mm	inch	Bar at 20℃	Psi at 68℉	mm	ft
10	3/8	6.0	0.24	10	145.0	40	1.58
13	1/2	6.0	0.24	10	145.0	45	1.77
16	5/8	6.0	0.24	10	145.0	55	2.17
19	3/4	6.0	0.24	10	145.0	65	2.56
25	1	6.0	0.24	10	145.0	85	3.35
32	1 1/4	6.0	0.24	10	145.0	120	4.72
38	1 1/2	6.5	0.26	10	145.0	140	5.51
51	2	8.0	0.31	10	145.0	180	7.09
63.5	2 1/2	8.0	0.31	5	72.5	320	12.60
76	3	8.0	0.31	5	72.5	380	14.96
100	4	9.0	0.35	5	72.5	500	19.69
