Chemical resistant silicone hose with conductive USP VI PFA inner layer
Venaflon® HF-XChemical resistant silicone hose with conductive USP VI PFA inner layer
Venaflon® HF-X
Chemical resistant silicone hose with conductive USP VI PFA inner layer
Silicone hose with an inner layer of conductive PFA, compatible with highly aggressive chemicals.
APPLICATIONS
It is specially recommended for the transport of liquids or semi-liquids food or pharma stuffs by impulsion or suction where is required a high conductivity to avoid electrostatic charge. It presents a wide field of application due to its construction which gives it a balance between strength and lightness. Suitable for its use in ATEX certified zones.
G.O.Science T: 031-375-6493 E-Mail : info@gosci.co.kr
FEATURES
| Customization | ○ Outer later Telcra- Insulating material | Outer Layer | ○ VMQ Silicone, smooth and translucent |
| ○ Reinforcement - | Reinforcement | ○ Stainless steel wire spring and polyester fabric reinforcement. | |
○ Traceability Silicone label QR Marking Special marking | Inner Layer | ○ Conductive PFA fluoropolymer, smooth and black | |
○ Assemblies 316L Stainless steel SZR crimp fittings Molded clamps | Temperature | ○ -30ºC / +150ºC (-22ºF / 302ºF) | |
| Manufacturing Length | ○ 20m (65.62 ft). Can be cutted under request. | ||
| Vacuum Pressure | ○ 0.9 Bar (13.05 psi). | ||
| Quality | ○ - | ||
SPECIFICATIONS
| INNER DIAMETER | WALL THICKNESS | WORKING PRESSURE | BENDING RADIUS | ||||
| mm | inch | mm | inch | Bar at 20℃ | Psi at 68℉ | mm | ft |
| 13 | 1/2 | 6.0 | 0.24 | 10 | 145.04 | 120 | 4.72 |
| 19 | 3/4 | 6.0 | 0.24 | 10 | 145.04 | 120 | 4.72 |
| 25 | 1 | 6.0 | 0.24 | 10 | 145.04 | 150 | 5.91 |
| 32 | 1 1/4 | 6.0 | 0.24 | 10 | 145.05 | 200 | 7.87 |
| 38 | 1 1/2 | 6.5 | 0.26 | 10 | 145.05 | 250 | 9.84 |
| 51 | 2 | 8.0 | 0.31 | 10 | 145.05 | 300 | 11.81 |
| 63.5 | 2 1/2 | 8.0 | 0.31 | 10 | 72.52 | 380 | 14.96 |
| 76 | 3 | 8.0 | 0.31 | 10 | 72.52 | 460 | 18.11 |
QR marking
The QR hose label can be marked in any FDA silicone hose without distorting any characteristic of the hose. This hose label assures 100% traceability allowing to have a more efficent system for product data reading. It’s an alternative to the chip system, the most commonly used in the market, however, it presents much more advantages:
Silicone color labels
Venair also offers the possibility to include silicone labels over any hose in order to mark specific information that you require.
Labels offer clear identification, cleanliness and permanence in the silicone hose. The label is not in contact with the inner liquid and it’s made of permanent vulcanized silicone, certified free of animal-derived ingredients. Additionally, handles CIP and SIP processes and it’s autoclavable.
Silicone labels can be customized with more than 15 colors in order to meet your specific needs such as part number, manufacturing date, replacement date, or any specific information that you consider to be important.
