Venaflon® HR - G.O.S 지오사이언스

Customization	○ Outer later -	Outer Layer	○ EPDM rubber, rough and blue.
	○ Reinforcement -	Reinforcement	○ Stainless steel wire spring and polyester fabric reinforcement.
	○ Traceability QR Marking Special marking	Inner Layer	○ PFA fluoropolymer, smooth and white.
	○ Assemblies 316L Stainless steel SZR crimp fittings Molded clamps	Temperature	○ -40ºC / +150C (-40ºF / 302ºF)
		Manufacturing Length	○ 20m (65.62 ft). Can be cutted under request.
		Vacuum Pressure	○ 0.9 Bar (13.05 psi).
Quality	○ -

The QR hose label can be marked in any FDA silicone hose without distorting any characteristic of the hose. This hose label assures 100% traceability allowing to have a more efficent system for product data reading. It’s an alternative to the chip system, the most commonly used in the market, however, it presents much more advantages:

It is marked in the silicone with a laser which makes it indelible
It doesn’t need any additional software
Can be read with all kind of mobile device which has downloaded an app to read codes, which are completely free
Can provide unlimited amounts of information about the product allowing you to customize the data content

INNER DIAMETER		WALL THICKNESS		WORKING PRESSURE		BENDING RADIUS
mm	inch	mm	inch	Bar at 20℃	Psi at 68℉	mm	ft
13	1/2	6.0	0.24	10	145	60	2.4
16	5/8	6.0	0.24	10	145	75	2.9
19	3/4	6.0	0.24	10	145	90	3.5
25	1	6.0	0.24	10	145	140	5.5
32	1 1/4	6.5	0.26	10	145	200	7.8
38	1 1/2	6.5	0.26	10	145	250	9.8
51	2	7.25	0.28	10	145	300	11.8
63.5	2.5	8.0	0.31	10	145	380	14.9
76	3	8.0	0.31	10	145	500	19.6
100	3.9	8.5	0.33	10	145	600	24.0
